PaveDrain® Heated for walkways and driveways:

Eliminate the need for harmful salt to keep concrete and asphalt snow and ice free. Salt has been used since 1942 to keep concrete and asphalt snow and ice free. However, its impact is proving to be harmful to the environment and infrastructure. The PaveDrain Heated system infiltrates at over 1,000 inches per hour (ASTM C1701). When HEATED the snow or ice does NOT run off and freeze downhill causing problems or liabilities for your neighbors. The PaveDrain system is environmentally friendly year round.

Learn More

Pave Tank™ high volume water storage:

Infiltration, treatment, and storage in one. Pave Tank™ offers a storage system for stormwater infiltration and retention solutions. This modular storage system has an HS-20 vehicle loading rating. Modules with baseplates can be stacked in multiple layers and mechanically connected to form almost any configuration – creating one of the lowest cost per cubic foot of underground storage available.

Learn more

The P4 INFIL-Tracker Monitoring system.

Existing PaveDrain® installations can easily be retrofitted with the P4 INFIL-Tracker Monitoring system. The P4 INFIL-Tracker and P4 Rain-mX monitoring systems autonomously measure the water level under the PaveDrain system before, during and after a storm event. Measure runoff volume captured and infiltration rate to drive data-driven TMDL compliance and document maintenance requirements.

Go to Webinar

Our exclusive on-demand PaveDrain Webinar!

Receive a 1 hour PDH certificate after successfully completing the webinar.

For centuries, engineers and architects have known that the arch is the strongest shape known to man. The PaveDrain® block combines the structural concept of the arch with modern-day functionality to become the premier Permeable Articulating Concrete Block (P-ACB) paving surface.

The PaveDrain system is the most environmentally friendly, cost-effective,
and MAINTAINABLE permeable system on the market.

The arch creates an internal storage chamber that can be filled with stormwater runoff in extreme conditions.

The PaveDrain system can be mechanically installed with a mini-excavator and a minimal crew.

The arch maintains strength even under massive loads and is rated for AASHTO HS-25 loading.

After vacuuming, there is no need to refill the joints between the blocks with sand or rock chips.

The PaveDrain system is set on compacted AASHTO No. 57 stone and a rigid biaxial geogrid that minimizes dislodging stone due to foot traffic and mechanical installation.

Most projects require some form of hand placed installation.

The arch allows the PaveDrain blocks to reach and maintain thermal mass quickly and efficiently.

The P4 INFIL-Tracker in the PaveDrain Cross Section will electronically tell you HOW MUCH stormwater you have captured and when the system needs to be maintained.

PaveDrain® FAQs

Download Full Pavedrain FAQs PDF

What’s the cost of installing PaveDrain®?

＋

Installed Cost: $14–$18 per sq. ft.
Material Only: $7–$8.50 per sq. ft.
*Color options add $1–$1.50 per sq. ft.*

Learn More

How is PaveDrain® maintained?

＋

Minimal maintenance needed. Vacuum trucks can clean clogged joints. Blocks are individually replaceable.

Learn More

What’s the infiltration rate of the PaveDrain® system?

＋

Over 1,500 inches/hour—among the highest. Verified via ASTM C1701 testing.

Learn More

What’s the load capacity of PaveDrain®?

＋

Rated AASHTO HS-25—suitable for heavy vehicles.

Learn More

How does PaveDrain® handle freeze/thaw cycles?

＋

Its interlocking, flexible design handles freeze/thaw well. Water drains before it can freeze inside the structure.

Learn More

How much open area does PaveDrain® provide?

＋

20% internal void space, 7% surface void space.

Learn More

How much water can PaveDrain® store?

＋

Up to 0.491 acre-ft per acre with 1 ft rock base—handles 100-year storms.

Learn More

Is PaveDrain® available in different colors?

＋

Yes. Earth tones standard. Custom colors available with 5,000 sq. ft. minimum.

Learn More

How do you replace a broken PaveDrain® block?

＋

Use the PaveDrain® Extraction Tool or pull blocks like “Jenga” for quick replacement.

Learn More

Can PaveDrain® be plowed with a steel snowplow?

＋

Yes. Rubber-tipped blades recommended to protect edges.

Learn More

Should PaveDrain® be sealed?

＋

Sealing helps protect against salt/brine damage and extends visual appeal in cold regions.

Learn More

What’s the life expectancy of PaveDrain®?

＋

25+ years. Individual block replacement ensures long-term maintenance.

Learn More

Is PaveDrain® ADA compliant?

＋

Yes. Gaps under ¼" and surface is firm, stable, and slip-resistant.

Learn More

Can I paint stripes on PaveDrain®?

＋

Yes. Standard road striping paint works fine.

Learn More

Does PaveDrain® qualify for LEED points?

＋

Up to 6 LEED credits possible: stormwater, regional materials, innovation, and more.

Learn More

PaveDrain® blocks come in multiple colors! Learn More.
